Gas-Liquid Two Phase Flow Behavior Related to ECLSS

JAXA Supercomputer System Annual Report February 2024-January 2025

Report Number: R24ECWU77

Subject Category: Cooperative Graduate School System

PDF available here

  • Responsible Representative: Masato Sakurai, Manager of ECLSS, Research Unit II, Aerospace RInsertHereD Directorate, JAXA
  • Contact Information: Masato Sakurai(sakurai.masato@jaxa.jp)
  • Members: Hikono Furuichi, Motoharu Kusano, Gaku Murakami, Masato Sakurai

Abstract

Elucidate the effects of gravity on gas-liquid two-phase flows to develop separation techniques for gas-liquid two-phase flows generated by the operation of the Environment Control and Life Support System (ECLSS).

Reference URL

N/A

Reasons and benefits of using JAXA Supercomputer System

To establish gas-liquid separation technology, it is necessary to evaluate the interfacial behavior of gas-liquid two-phase flows under the influence of gravity. Large-scale and high-speed numerical simulations are essential for conducting this research on Earth, and the vast computational resources provided by JSS are crucial.

Achievements of the Year

In order to investigate the effect of surface properties in a container on gas-liquid two-phase flow, the behavior of gas-liquid two-phase flow in a sealed container with hydrophobic wall surfaces was examined. It was found that the hydrophobic wall surface suppressed the liquid behavior more than the hydrophilic wall surface.(Figure 1)

Annual Report Figures for 2024

Fig.1: Liquid behavior in containers with different wall wettability (i) hydrophobic model (ii) hydrophilic model



Publications

- Oral Presentations

Effect of gravity conditions on Sloshing Phenomena in Sealed Vessel

Usage of JSS

Computational Information

  • Process Parallelization Methods: MPI
  • Thread Parallelization Methods: OpenMP
  • Number of Processes: 144 - 324
  • Elapsed Time per Case: 24 Hour(s)

JSS3 Resources Used



Fraction of Usage in Total Resources*1(%): 0.04



Details

Please refer to System Configuration of JSS3 for the system configuration and major specifications of JSS3.

Computational Resources
System Name CPU Resources Used
(Core x Hours)
Fraction of Usage*2(%)
TOKI-SORA 0.00 0.00
TOKI-ST 155959.12 0.16
TOKI-GP 0.00 0.00
TOKI-XM 0.00 0.00
TOKI-LM 0.00 0.00
TOKI-TST 0.00 0.00
TOKI-TGP 0.00 0.00
TOKI-TLM 0.00 0.00



File System Resources
File System Name Storage Assigned
(GiB)
Fraction of Usage*2(%)
/home 245.00 0.17
/data and /data2 155985.00 0.75
/ssd 33230.00 1.78



Archiver Resources
Archiver Name Storage Used
(TiB)
Fraction of Usage*2(%)
J-SPACE 2.73 0.01

*1: Fraction of Usage in Total Resources: Weighted average of three resource types (Computing, File System, and Archiver).

*2: Fraction of Usage:Percentage of usage relative to each resource used in one year.



ISV Software Licenses Used

ISV Software Licenses Resources
ISV Software Licenses Used
(Hours)
Fraction of Usage*2(%)
ISV Software Licenses
(Total)
0.00 0.00

*2: Fraction of Usage:Percentage of usage relative to each resource used in one year.
